Print Head / Ink

Type

Permanent (Replaceable)

Number of Nozzles

Black: 640 nozzles (Optional Colour: 1152 nozzles)

Ink Bottles / Cartridges

GI-70 (Pigment Black)
Optional: CL-741, CL741XL

Maximum Printing Resolution

600 (horizontal)^*1 x 1200 (vertical) dpi

Print Speed^*2 (Approx.)

Click Here for Summary Report
Click Here for Document Print and Copy Speed Measurement Conditions

Document (ESAT/Simplex)

13 / 6.8 ipm (mono/colour)

Document (ESAT/Duplex)

4.8 / 2.8 ipm (mono/colour)

Document (FPOT Ready / Simplex)

9 / 14 sec (mono/colour)

Printable Width

Up to 203.2mm (8")

Printable Area

Borderless Printing^*3

-

Bordered Printing

#10 Envelope/DL Envelope:
Top margin: 8 mm, Bottom margin: 12.7 mm
Left/Right margin: 5.6 mm

LTR / LGL:
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 6.4 mm, Right margin: 6.3 mm

Others:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 3.4 mm

Bordered Auto 2-Sided Printing

Top/Bottom margin: 5 mm,
Left/Right margin: 3.4 mm
(LTR: Left: 6.4 mm, Right: 6.3 mm)

Support Media

Rear Tray

Plain Paper (64 - 105 g/m²)
High Resolution Paper (HR-101N)
Envelope

Cassette

Plain Paper (64 - 105 g/m²)

Paper Size

Rear Tray

A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91 x 55 mm)

[Custom size]
width 55 - 215.9 mm, length 89 - 676 mm

*F4 is possible via custom size settings.

Cassette

A4, A5, B5, LTR

[Custom size]
width 148.0 - 215.9 mm, length 210 - 297 mm

* F4 is possible via custom size settings.

Paper Handling (Maximum Number)

Rear Tray

Plain Paper (A4, 64 g/m²) = 100
High Resolution Paper (HR-101N) = 80

Cassette

Plain Paper (A4, 64 - 105 g/m²) = 250

Support Media for Auto 2-sided printing

Type

Plain Paper

Size

A4, A5, B5, LTR

Paper Weight

Rear Tray

Plain Paper: 64 - 105 g/m²

Cassette

Plain Paper: 64 - 105 g/m²

Ink End Sensor

Electrode type and dot count type combined
Optional colour cartridge; Dot count

Print Head Alignment

Auto/Manual

Protocol

TCP/IP, SNMP

Wired LAN

Network Type

IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)

Data Rate

10M/100Mbps (Auto switchable)

Wireless

Network Type

IEEE802.11b/g/n
2.4 GHz, Supported Channels: 1 - 13
(TW/HK: Supported Channels: 1 - 11 only)

Range

Indoor 50 m (Depends on the transmission speed and conditions)

Security

WEP64/128 bit
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Direct Connection (Wireless LAN)

Available

Canon Print Service
(for Android)

Available

Cloud Service
(from smartphone/tablet)

Available

Canon PRINT
(for iOS/Android)

Available

Windows 10 / 8.1 / 7 SP1
(Operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)

Interface

USB 2.0

Operating Environment^*5

Temperature

5 - 35°C

Humidity

10 - 90% RH (no dew condensation)

Recommended Environment^*6

Temperature

15 - 30°C

Humidity

10 - 80% RH (no dew condensation)

Storage Environment

Temperature

0 - 40°C

Humidity

5 - 95% RH (no dew condensation)

Quiet Mode

Available

Acoustic Noise (PC Print)

Plain Paper (A4, Mono)^*7

52.0 dB(A)

Power

AC 100-240 V, 50/60 Hz

Power Consumption (Approx.)

OFF

0.3 W

Standby (scanning lamp is off)
USB connection to PC

0.8 W

Printing^*8
USB connection to PC

13 W

Duty Cycle

Up to 15,000 pages/month

Dimensions (WxDxH) (Approx.)

Factory Configuration

403 x 369 x 166 mm

Output/ADF Trays Extended

403 x 695 x 356 mm

Weight (Approx.)

6.0 kg

Plain Paper
Click Here for more information

A4 Monochrome Documents^*10:
GI-70 PGBK: 6,000 (Economy Mode^*11 8,300)

A4 Colour Documents^*12:
Optional:
CL-741: 180
CL-741XL: 400
